Fluctuation diagram — fd • snippets

Draws a fluctuation diagram.

fd(x, ...)
# S3 method for class 'matrix'
fd(x, add = FALSE, vals = FALSE, at.x, at.y, axes = TRUE,
frame.plot = FALSE, main = NULL, sub = NULL, xlab = NULL, ylab = NULL,
zmax = max(x, na.rm = TRUE), xlim, ylim, asp = 1, panel.first = NULL,
panel.last = NULL, ann = par("ann"), col = "grey", border = "black",
...)
# S3 method for class 'table'
fd(x, add = FALSE, vals = FALSE, at.x, at.y, axes = TRUE,
frame.plot = FALSE, main = NULL, sub = NULL, xlab = NULL, ylab = NULL,
zmax = max(x, na.rm = TRUE), xlim, ylim, asp = 1, panel.first = NULL,
panel.last = NULL, ann = par("ann"), col = "grey", border = "black",
...)

Arguments

x: object to draw fluctuation diagram of (most commonly a table)
add: a logical value indicating whether to add to an existing plot (TRUE) or to create a new plot (FALSE).
vals: a logical value indicating whether to draw values into the rectangles (discouraged and unimplemented).
at.x: locations of the colums (by default 1:ncol)
at.y: locations of the rows (by default 1:nrow)
axes: a logical value indicating whether both axes should be drawn on the plot. Use graphical parameter xaxt or yaxt to suppress just one of the axes.
frame.plot: a logical indicating whether a box should be drawn around the plot.
main: a main title for the plot, see also title.
sub: a subtitle for the plot.
xlab: a label for the x axis.
ylab: a label for the y axis.
zmax: value representing the total size of an allocated box.
xlim: the x limits (x1, x2) of the plot. The default is the range of at.x with an additional 0.5 margin of the ends.
ylim: the y limits of the plot.
asp: the y/x aspect ratio, see plot.window.
panel.first: an expression to be evaluated after the plot axes are set up but before any plotting takes place. This can be useful for drawing background grids
panel.last: an expression to be evaluated after plotting has taken place.
ann: see "ann" graphical parameter
col: color of the boxes to be filled with, will be recycled to match the shape of x.
border: color of the box borders - only scalar value is supported at the moment.
...: additional graphical parameters

Value

Returns (invisibly) a data frame describing the sparse representation of the boxes as location and radius.

Examples

## this is best viewed on a wide-screen device...
par(mfrow=c(1,2))
for (sex in dimnames(HairEyeColor)$Sex)
  fd(HairEyeColor[,,sex], main=sex)
