Summarize capture histories in individual fish format.

Use to summarize a capture history data file that is in the “individual” fish format (see capHistConvert for a discussion of data file format types). Summarized capture history results may be used in the Lincoln-Petersen, Schnabel, Schumacher-Eschmeyer, or Jolly-Seber methods for estimating population abundance (see mrClosed and mrOpen).

Usage

capHistSum(df, cols2use = NULL, cols2ignore = NULL)

is.CapHist(x)

# S3 method for CapHist
plot(x, what = c("u", "f"), pch = 19, cex.pch = 0.7, lwd = 1, ...)

Arguments

df: A data.frame that contains the capture histories (and, perhaps, other information) in “individual” fish format. See details.
cols2use: A string or numeric vector that indicates columns in df that contain the capture histories. Negative numeric values will not use those columns. Cannot use both cols2use and col2ignore. See details.
cols2ignore: A string or numeric vector that indicates columns in df that do not contain the capture histories and should be ignored. Cannot use both cols2use and col2ignore.
x: An object from capHistSum.
what: A string that indicates what type of diagnostic plot to construct with plot. See details.
pch: A numeric that indicates the plotting character for the diagnostic plot.
cex.pch: A numeric that indicates the character expansion value for the plotting characters in the diagnostic plot. The default is to be “slightly smaller” (i.e., cex.pch=0.7).
lwd: A numeric that indicates the line width in the diagnostic plot.
...: Optional arguments to send to plot.

Value

If the capture history data file represents only two samples, then a list with the following two components is returned.

caphist A vector summarizing the frequency of fish with each capture history.
sum A data.frame that contains the number of marked fish from the first sample (M), the number of captured fish in the second sample (n), and the number of recaptured (i.e. previously marked) fish in the second sample (m).

If the capture history data file represents more than two samples, then a list with the following five components is returned

caphist A vector summarizing the frequency of fish with each capture history.
sum A data frame that contains the the number of captured fish in the ith sample (n), the number of recaptured (i.e. previously marked) fish in the ith sample (m), the number of marked fish returned to the population following the ith sample (R; this will equal n as the function currently does not handle mortalities); the number of marked fish in the population prior to the ith sample (M); the number of fish first seen in the ith sample (u); the number of fish last seen in the ith sample (v); and the number of fish seen i times (f).
methodB.top A matrix that contains the top of the Method B table used for the Jolly-Seber method (i.e., a contingency table of capture sample (columns) and last seen sample (rows)).
methodB.bot A data.frame that contains the bottom of the Method B table used for the Jolly-Seber method (i.e., the number of marked fish in the sample (m), the number of unmarked fish in the sample (u), the total number of fish in the sample (n), and the number of marked fish returned to the population following the sample (R).
m.array A matrix that contains the the so-called “m-array”. The first column contains the number of fish captured on the ith event. The columns labeled with “cX” prefix show the number of fish originally captured in the ith row that were captured in the Xth event. The last column shows the number of fish originally captured in the ith row that were never recaptured.

Details

This function requires the capture history data file to be in the “individual” fish format. See capHistConvert for a description of this (and other) formats and for methods to convert from other formats to the “individual” fish format. In addition, this function requires only the capture history portion of the data file. Thus, if df contains columns with non-capture history information (e.g., fish ID, length, location, etc.) then use cols2use= to identify which columns contain only the capture history information. Columns to use can be identified by listing the column numbers (e.g., columns 2 through 7 could be included with cols2use=2:7). In many instances it may be easier to identify columns to exclude which can be done by preceding the column number by a negative sign (e.g., columns 1 through 3 are excluded with cols2use=-(1:3)).

The object returned from this function can be used directly in mrClosed and mrOpen. See examples of this functionality on the help pages for those functions.

The plot function can be used to construct the two diagnostic plots described by Baillargeon and Rivest (2007). The what="f" plot will plot the log of the number of fish seen i times divided by choose(t,i) against i. The what="u" plot will plot the log of the number of fish seen for the first time on event i against i. Baillargeon and Rivest (2007) provide a table that can be used to diagnosed types of heterogeneities in capture probabilities from these plots.

Note

This function assumes that all unmarked captured fish are marked and returned to the population (i.e., no losses at the time of marking are allowed).

IFAR Chapter

9-Abundance from Capture-Recapture Data.

References

Ogle, D.H. 2016. Introductory Fisheries Analyses with R. Chapman & Hall/CRC, Boca Raton, FL.

Baillargeon, S. and Rivest, L.-P. (2007). Rcapture: Loglinear models for capture-recapture in R. Journal of Statistical Software, 19(5):1-31.

Author

Derek H. Ogle, DerekOgle51@gmail.com

Examples

# data.frame with IDs in the first column
head(PikeNYPartial1)
#>     id first second third fourth
#> 1 2001     1      0     0      0
#> 2 2002     1      0     0      0
#> 3 2003     1      0     0      0
#> 4 2004     1      0     0      0
#> 5 2005     1      0     0      0
#> 6 2006     1      0     0      0

# Three ways to ignore first column of ID numbers
( ch1 <- capHistSum(PikeNYPartial1,cols2use=-1) )
#> $caphist
#>
#> 0001 0010 0011 0100 0101 0110 1000 1001 1010 1100
#>    5    8    2   12    1    2   21    1    2    3
#>
#> $sum
#>    n m  R  M  u  v  f
#> 1 27 0 27  0 27 21 46
#> 2 18 3 18 27 18 15 11
#> 3 14 4 14 42 10 14  0
#> 4  9 4  0 52  5  9  0
#>
#> $methodB.top
#>     i=1 i=2 i=3 i=4
#> j=1  NA   3   2   1
#> j=2  NA  NA   2   1
#> j=3  NA  NA  NA   2
#> j=4  NA  NA  NA  NA
#>
#> $methodB.bot
#>   i=1 i=2 i=3 i=4
#> m   0   3   4   4
#> u  27  15  10   5
#> n  27  18  14   9
#> R  27  18  14   0
#>
#> $m.array
#>     ni c2 c3 c4 not recapt
#> i=1 27  3  2  1         21
#> i=2 18 NA  2  1         15
#> i=3 14 NA NA  2         12
#> i=4  9 NA NA NA          9
#>
#> attr(,"class")
#> [1] "CapHist"
( ch1 <- capHistSum(PikeNYPartial1,cols2ignore=1) )
#> $caphist
#>
#> 0001 0010 0011 0100 0101 0110 1000 1001 1010 1100
#>    5    8    2   12    1    2   21    1    2    3
#>
#> $sum
#>    n m  R  M  u  v  f
#> 1 27 0 27  0 27 21 46
#> 2 18 3 18 27 18 15 11
#> 3 14 4 14 42 10 14  0
#> 4  9 4  0 52  5  9  0
#>
#> $methodB.top
#>     i=1 i=2 i=3 i=4
#> j=1  NA   3   2   1
#> j=2  NA  NA   2   1
#> j=3  NA  NA  NA   2
#> j=4  NA  NA  NA  NA
#>
#> $methodB.bot
#>   i=1 i=2 i=3 i=4
#> m   0   3   4   4
#> u  27  15  10   5
#> n  27  18  14   9
#> R  27  18  14   0
#>
#> $m.array
#>     ni c2 c3 c4 not recapt
#> i=1 27  3  2  1         21
#> i=2 18 NA  2  1         15
#> i=3 14 NA NA  2         12
#> i=4  9 NA NA NA          9
#>
#> attr(,"class")
#> [1] "CapHist"
( ch1 <- capHistSum(PikeNYPartial1,cols2ignore="id") )
#> $caphist
#>
#> 0001 0010 0011 0100 0101 0110 1000 1001 1010 1100
#>    5    8    2   12    1    2   21    1    2    3
#>
#> $sum
#>    n m  R  M  u  v  f
#> 1 27 0 27  0 27 21 46
#> 2 18 3 18 27 18 15 11
#> 3 14 4 14 42 10 14  0
#> 4  9 4  0 52  5  9  0
#>
#> $methodB.top
#>     i=1 i=2 i=3 i=4
#> j=1  NA   3   2   1
#> j=2  NA  NA   2   1
#> j=3  NA  NA  NA   2
#> j=4  NA  NA  NA  NA
#>
#> $methodB.bot
#>   i=1 i=2 i=3 i=4
#> m   0   3   4   4
#> u  27  15  10   5
#> n  27  18  14   9
#> R  27  18  14   0
#>
#> $m.array
#>     ni c2 c3 c4 not recapt
#> i=1 27  3  2  1         21
#> i=2 18 NA  2  1         15
#> i=3 14 NA NA  2         12
#> i=4  9 NA NA NA          9
#>
#> attr(,"class")
#> [1] "CapHist"

# diagnostic plots
plot(ch1)

plot(ch1,what="f")

plot(ch1,what="u")


# An examle with only two sample events (for demonstration only)
( ch2 <- capHistSum(PikeNYPartial1,cols2use=-c(1,4:5)) )
#> $caphist
#>
#> 00 01 10 11
#> 15 15 24  3
#>
#> $sum
#>    M  n m
#> 1 27 18 3
#>
#> attr(,"class")
#> [1] "CapHist"
( ch2 <- capHistSum(PikeNYPartial1,cols2use=2:3) )
#> $caphist
#>
#> 00 01 10 11
#> 15 15 24  3
#>
#> $sum
#>    M  n m
#> 1 27 18 3
#>
#> attr(,"class")
#> [1] "CapHist"
( ch2 <- capHistSum(PikeNYPartial1,cols2ignore=c(1,4:5)) )
#> $caphist
#>
#> 00 01 10 11
#> 15 15 24  3
#>
#> $sum
#>    M  n m
#> 1 27 18 3
#>
#> attr(,"class")
#> [1] "CapHist"
